176 杨智，朱朋，徐聪，张秋，覃新，沈瑞琪

Hu Bo，Li Jie，Zhu Peng，et al. Experimental investigation of gap switch with three electrodes［J］. Materials Science Forum，
one⁃shot switch based on parylene C［J］. High Power Laser 2011，694：485-489.
and Particle Beams，2015，27（6）：233-237. ［44］ Liu C，Yang Z，Ding G，et al. Design，Simulation，and charac⁃
［34］ 胡博，朱朋，沈瑞琪，等 . 封装材料对单触发开关的性能影响研 terization of a low⁃cost in⁃plane spark gap microswitch with du⁃
究［J］. 爆破器材，2016（1）：22-25. al⁃trigger electrode for pulsed power applications［J］. IEEE Trans⁃
Hu Bo，Zhu Peng，SHEN Rui⁃qi，et al. Experimental study on actions on Industrial Electronics，2013，60（8）：3240-3247.
the effect of the packaging material on switch characteristics of ［45］ Zeng Q X，Lv J J，Li M Y. Fabrication and testing of metal foil
one⁃shot switch［J］. Explosive Materials，2016（1）：22-25. planar switch［J］. Defence Technology，2013，9（2）：80-84.
［35］ Waschl J A，Hatt D J. Characterization of a small⁃scale explod⁃ ［46］ Lv J，Zeng Q，Li M. Metal foil gap switch and its electrical proper⁃
ing bridge foil flyer generator［J］. International Journal of Im⁃ ties.［J］. Review of Scientific Instruments，2013，84（4）：150-154.
pact Engineering，1993，14（1-4）：785-796. ［47］ 李志浩 . 爆炸箔起爆系统高压平面固体开关技术研究［D］. 北
［36］ Woodworth J，Stygar W，Bennett L，et al. New low induc⁃ 京：北京理工大学，2016.
tance gas switches for linear transformer drivers［J］. Physical LI Zhi⁃hao. The technical research on planar solid high⁃voltage
Review Special Topics⁃Accelerators and Beams， 10.1103 / switch in exploding foil initiating system［D］. Beijing：Beijing
PhysRevSTAB.13.080401. Institute of Technology，2016.
［37］ Baginski T A. Integrated spark gap device：US 6977468B1［P］. ［48］ O'Brien D W，Druce R L，Johnson G W，et al. Method and
2005. system for making integrated solid⁃state fire⁃sets and detona⁃
［38］ Baginski T A，Dean R N，Wild E J. Micromachined planar trig⁃ tors：US 5731538A［P］. 1998.
gered spark gap switch［J］. IEEE Transactions on Components ［49］ Nickolin. ESAD technology benefits to ISD［C］//49th Annual
Packaging & Manufacturing Technology，2011，1（9）：1480-1485. Fuze Conference，Seattle，Washington，2005.
［39］ 王桂吉，吴刚，赵剑衡，等 . 平面火花隙三电极开关研制及性能 ［50］ e2v，lnc. e2v ordnance safety and arming（OS&A）capability
测试［J］. 强激光与粒子束，2006，18（2）：349-352. overview［EB /OL］. http：//www.e2v.com /products⁃and⁃servic⁃
WANG Gui⁃ji，WU Gang，ZHAO Jian⁃heng，et al. Develop⁃ es/rf⁃power⁃solutions/safety⁃and⁃arming⁃devices，2009⁃01⁃02.
ment on planar spark gap switch with three electrodes［J］. ［51］ Scholtes J H G，Prinse W C，Bouma R H B，et al. Develop⁃
High Power Laser and Particle Beams，2006，18（2）：349-352. ment of exploding foil initiators for future IM［C］//2007 Insensi⁃
［40］ 丁 桂 甫 ，周 镇 威 ，杨 卓 青 ，等 . 微 型 平 面 式 气 体 火 花 隙 开 关 ： tive Munitions & Energetic Materials Technology Symposium
CN，CN101814701A［P］. 2010. （IMEMTS）：“New Programs，New Policies，New Strategies
DING Gui⁃fu ，ZHOU Zhen⁃wei，YANG Zhuo⁃qing，et al. Mi⁃ leading to New Joint Solutions”，Miami，FL，USA，15-48 Oc⁃
cro planar gas spark switch：CN 101814701A［P］. 2010. tober 2007，9p.（article）+21 sheets.
［41］ 周镇威，杨卓青，丁桂甫，等 . 微型平面式气体火花开关的设计 ［52］ Prinse W，Scholtes G. A development platform for a micro⁃
和制作［J］. 强激光与粒子束，2012，24（5）：1256-1260. chip EFI［C］//52th Annual Fuze Conference. Kansas City，
ZHOU Zhen⁃wei，YANG Zhuo⁃qing，DING Gui⁃fu，et al. De⁃ 2008，3：13-15.
sign and fabrication of micro planar gas spark switch［J］. High ［53］ 周密，任西，钱勇，等 . 平面开关与爆炸桥箔的集成设计及研究
Power Laser and Particle Beams，2012，24（5）：1256-1260. ［J］. 火工品，2011（5）：33-35.
［42］ Zhao X，Zhou Z，Ding G，et al. A planar micro spark gap ZHOU Mi，REN Xi，QIAN Yong，et al. Study on integration of
switch with a triggering electrode［J］. Micro & Nanosystems， plane switch and exploding foil［J］. Initiators & Pyrotechnics，
2011，3（4）. 2011（5）：33-35.
［43］ Shen H，Ding G F，Zhou Z W，et al. A micro triggered spark

Review on Micro Chip Exploding Foil Initiator and Its Planar High⁃voltage Switch

YANG Zhi，ZHU Peng，XU Cong，ZHANG Qiu，QIN Xin，SHEN Rui⁃qi
（School of Chemical Engineering，Nanjing University of Science and Technology，Nanjing 210094，China）

Abstract：Each technology upgrading of Exploding Foil Initiator system（EFIs）is accompanied with the innovation of design con⁃
cepts and manufacture processes，especially the technologies of Micro Electro Mechanical System（MEMS）and Low Tempera⁃
ture Co⁃fired Ceramics（LTCC）greatly promote the development of Micro Chip Exploding Foil Initiator system（McEFIs）. The ad⁃
vantages and disadvantages of Micro Chip Exploding Foil Iinitiator（McEFI）fabricated by two kinds of processes were briefly ana⁃
lyzed. The working performances of several planar high⁃voltage switches in Capacitor Ddischarge Unit（CDU）were listed，and
the feasibility of manufacture idea and research method of the switch is obtained. The research progress at home and abroad
based on the preparation of MEMS process and LTCC process，and the study of McEFI，planar high⁃voltage switch as well as pla⁃
nar high⁃voltage switch integrated with McEFI was summarized respectively. Key research directions were put forward. In⁃depth
research of the fabrication of McEFI and its planar high⁃voltage switch by the MEMS process will achieve engineering application.
The planar high⁃voltage switch & McEFI with monolithic structure can be fabricated by LTCC technology.
Key words：Micro Chip Exploding Foil Initiator system（McEFIs）；capacitor discharge unit；Micro Chip Exploding Foil Initiator
（McEFI）；planar high⁃voltage switch；research progress
CLC number：TJ45 Document code：A DOI：10.11943/CJEM2018146
