低 温 动 态 加 载 下 三 组 元 HTPB 复 合 固 体 推 进 剂 的 失 效 判 据
［23］ Method for determining the tensile properties of solid rocket ［26］ 张 兴 高 . HTPB 推 进 剂 贮 存 老 化 特 性 及 寿 命 预 估 研 究［D］. 长
propellants［M］. CPIA Publish SPIA，1957：8. 沙：国防科学技术大学，2009.
［24］ 赖建伟 . 固体推进剂药柱低温力学性能与结构完整性研究［D］. ZHANG Xing‑gao. Study on the aging properties and storage
西安：火箭军工程大学，2013. life prediction of HTPB propellant［D］. Changsha：National
LAI Jian‑wei. Research on mechanical properties and structural University of Defense Technology，2009.
integrity of solid propellant grain at low temperature［D］. ［27］ Nevie`re R. An extension of the time‑temperature superposi‑
Xi′an：Xi′an Hi‑Tech Institute，2013. tion principle to non‑linear viscoelastic solids［J］. International
Journal of Solids and Structures，2006，43（17）：5295-5306.
［25］ 张晓军，常新龙，赖建伟，等 . HTPB 推进剂低温拉伸/压缩力学
性能对比［J］. 固体火箭技术，2013，36（6）：771-774. ［28］ 侯林法 . 复合固体推进剂［M］. 北京：中国宇航出版社，2009：
ZHANG Xiao‑jun， CHANG Xin‑long， LAI Jian‑wei， et al. 382-383.
Comparative research of tensile and compressive mechanical HOU Lin‑fa. Composite solid propellant［M］. Beijing：China
properties of HTPB propellant at low temperature［J］. Journal Astronautic Publishing House，2009：382-383.
of Solid Rocket Technology，2013，36（6）：771-774.

Failure Criteria of Three⁃component HTPB Composite Solid Propellant at Low Temperature Under Dynamic
Loading

QIANG Hong⁃fu，WANG Zhe⁃jun，WANG Guang，GENG Biao
（Xi′an Hi‑Tech Institute，Xi′an 710025，China）
Abstract：Based on uniaxial and quasi‑biaxial tensile tests and microscopic damage observation experiments of three‑component

Hydroxyl‑Terminated Polybutadience（HTPB）composite solid propellant at different thermal accelerated aging time（0，32，74，
98 d），temperatures（-50，-40，-30，-20，25 ℃）and strain rates（0.40，4.00，14.29，42.86，63 s ），the effects of loading
-1
conditions on the initial elastic modulus，strength and the corresponding strain have been analyzed. Moreover，failure criteria of
the propellant under the tests have been determined. It has been indicated that HTPB propellant fails more easily due to tensile
stress under dynamic uniaxial loading，and the thermal aging can further reduce this capability. Thus the strain at maximum ten‑
sile stress can be considered as the uniaxial failure criterion. In addition，tensile‑compressive strength ratio can better reflect the
different properties of the propellants under dynamic uniaxial loading. This value is 0.4 and 0.2-0.3 at room temperature and
low temperatures，respectively. The strain at maximum tensile stress of HTPB propellant under quasi‑biaxial tension is significant‑
ly lower than that in uniaxial tension. Furthermore，the extent of reduction increases with extended aging time and decreased
temperature. The proportion for unaged and aged propellants is 60%-85% and 40%-60%，respectively. Finally，this strain is in‑
dependent of stress state and strain rate at the lower temperature and higher strain rates. Thus the strain at maximum tensile stress
under dynamic biaxial tension can be considered as the failure criterion of HTPB propellant. It can also be used to analyze the
structure integrity of propellant grains for tactical missiles during ignition of solid rocket motor（SRM）. Moreover，its value can
be determined with the master curves and aging models.
Key words：Hydroxyl‑Terminated Polybutadience（HTPB）propellant；failure criteria；low temperature；dynamic loading；thermal
accelerated aging
CLC number：TJ55；V512 Document code：A DOI：10.11943/CJEM2018340
